CL5808/CL5816 User Manual
40
Setting
Function
EDIT PORT
NAMES
To help remember which computer is attached to a particular port,
every port can be given a name. This function allows the
administrator to create, modify, or delete port names. To edit a port
name:
1. Click the port, or use the navigation keys to move the highlight bar
to it, then press
[Enter]
.
2. Key in the new port name, or modify/delete the old one. The maxi-
mum number of characters allowed for the port name is 12. Legal
characters include:
All alpha characters:
A
–
Z
All numeric characters:
0
–
9
* ( ) + : - , ? . /
and
Space
Case does not matter; OSD displays the port name in all
capitals no matter how they were keyed in.
3. When you have finished editing, press
[Enter]
to have the
change take effect. To abort the change, press
[Esc]
.
RESTORE
DEFAULT
VALUES
This function is used to undo all changes and return the setup to the
original factory default settings (see
OSD
FACTORY DEFAULT
SETTINGS
, page 63) except for the port name list, username and
password information, which are saved.
CLEAR THE
NAME LIST
This function clears the port name list.
ACTIVATE
BEEPER
Choices are
Y
(on), or
N
(off). When activated, the beeper sounds
whenever a port is changed; when activating the Auto Scan function
(see
F7 SCAN
, page 44); or an invalid entry is made on an OSD
menu. The default is
Y
.
SET QUICK
VIEW PORTS
This function lets the administrator select which ports to include as
quick view ports.
To select/deselect a port as a quick view port, double-click the port,
or use the navigation keys to move the highlight bar to it, then press
[Spacebar]
.
When a port has been selected as a quick view port, an icon dis-
plays in the QV column of the LIST on the main screen.
If one of the quick view options is chosen for the LIST view (see
F2
LIST
, page 35), only a port that has been selected here
will display on the list.
If one of the quick view options is chosen for auto scanning
(see
SCAN/SKIP MODE
, page 37), only a port that has been
selected here will be auto scanned.
The default has no ports selected for quick view.
