CL5808/CL5816 User Manual
38
F4: ADM
F4 is an administrator only function. It allows the administrator to configure
and control the overall operation of the OSD. To change a setting double-click
it, or use the up and down arrow keys to move the highlight bar to it then press
[Enter] .
After you select an item, a submenu with further choices to select from appears.
Double-click an item, or move the highlight bar to it then press
[Enter] . An
icon appears before the selected item so that you know which one it is. The
settings are explained in the following table:
Setting Function
SET USER
LOGIN Use this function to set login mode, usernames, passwords and
fingerprints for the administrator and users.
SET USERNAME AND PASSWORD
Š
Usernames and passwords for one administrator and four users
can be set.
Š
After you select the administrator field or one of the user fields, a
screen that allows you to key in the username and password
appears. Usernames and passwords can be from 1 to 16
characters long and can consist of any combination of letters
and numbers (A–Z, 0–9) and some additional keys (* ( ) + : - , ? .
/ space).
Š
For each individual, key in the username and password, confirm
the password, then press
[Enter] .
Š
To modify or delete a previous username and/or password, use
the backspace key to erase individual letters or numbers. Press
[Enter] when done.
Š
Usernames and passwords are not case sensitive. Usernames
are displayed in capital letters in the OSD.
SET FINGERPRINT:
Note: This setting is only available on models with a fingerprint
reader.
Selecting this option enables the fingerprint reader to record
fingerprints.
Fingerprints can be used in conjunction with, or in place of, a
username and password when logging in. Although up to 10
fingerprints can be scanned for each user account, a maximum of
20 fingerprints can be stored on the switch, depending on the size
of the fingerprint data file.
