Printer Parts
Front
A
Top cover
Open when a paper jam occurs or to perform maintenance.
B
Status display light
This light indicates when the printer's status is normal or if an error has occurred.
U
C
Power switch
This is normally ON (the
light is lit). If an emergency occurs, or when it is not going to be used for extended
periods of time, press the switch to turn off the printer (the
light turns off).
D
Ink light (orange)
U
E
Cartridge cover (left)
Open when replacing ink cartridges.
U
“Replacing Ink Cartridges” on page 45
F
Scrap paper box
Holds waste paper that is cut off during printing. Make sure you empty the box when replacing paper. Needs to be
removed when loading or removing paper.
U
“Emptying the Scrap Paper Box” on page 58
