[1]
On
Logic Controller is active.
13-01 Start Event
Option:
Function:
Select input to activate Logic Controller.
[0]
False
Enters False in logic rule.
[1]
True
Enters True in logic rule.
[2]
Running
See par. 5-4* [5] for description.
[3]
InRange
See par. 5-4* [7] for description.
[4]
OnReference
See par. 5-4* [8] for description.
[7]
Out of Current Range
See par. 5-4* [12] for description.
[8]
BelowILow
See par. 5-4* [13] for description.
[9]
AboveIHigh
See par. 5-4* [14] for description.
[16]
ThermalWarning
See par. 5-4* [21] for description.
[17]
MainsOutOfRange
Mains voltage is outside the specified voltage range.
[18]
Reversing
See par. 5-4* [25] for description.
[19]
Warning
A warning is active.
[20]
Alarm_Trip
A trip alarm is active.
[21]
Alarm_TripLock
A trip lock alarm is active.
[22]
Comparator 0
Use result of comparator 0 in logic rule.
[23]
Comparator 1
Use result of comparator 1 in logic rule.
[24]
Comparator 2
Use result of comparator 2 in logic rule.
[25]
Comparator 3
Use result of comparator 3 in logic rule.
[26]
LogicRule 0
Use result of logic rule 0 in logic rule.
[27]
LogicRule 1
Use result of logic rule 1 in logic rule.
[28]
LogicRule 2
Use result of logic rule 2 in logic rule.
[29]
LogicRule 3
Use result of logic rule 3 in logic rule.
[33]
DigitalInput_18
Use value of DI 18 in logic rule.
[34]
DigitalInput_19
Use value of DI 19 in logic rule.
[35]
DigitalInput_27
Use value of DI 27 in logic rule.
[36]
DigitalInput_29
Use value of DI 29 in logic rule.
[38]
DigitalInput_33
[39]
*
StartCommand
This event is True, if frequency converter is started by any means (digital input or other).
[40]
DriveStopped
This event is True, if frequency converter is stopped or coasted by any means (digital input or other).
13-02 Stop Event
Option:
Function:
Select input to activate Logic Controller.
[0]
False
Enters False in logic rule.
[1]
True
Enters True in logic rule.
[2]
Running
See par. 5-4* [5] for description.
[3]
InRange
See par. 5-4* [7] for description.
[4]
OnReference
See par. 5-4* [8] for description.
[7]
Out of Current Range
See par. 5-4* [12] for description.
[8]
BelowILow
See par. 5-4* [13] for description.
[9]
AboveIHigh
See par. 5-4* [14] for description.
[16]
ThermalWarning
See par. 5-4* [21] for description.
[17]
MainsOutOfRange
Mains voltage is outside the specified voltage range.
