[19] Warning A warning is active.
[20] Alarm_Trip A trip alarm is active.
[21] Alarm_TripLock A trip lock alarm is active.
[22] Comparator 0 Use result of comparator 0 in logic rule.
[23] Comparator 1 Use result of comparator 1 in logic rule.
[24] Comparator 2 Use result of comparator 2 in logic rule.
[25] Comparator 3 Use result of comparator 3 in logic rule.
[26] LogicRule 0 Use result of logic rule 0 in logic rule.
[27] LogicRule 1 Use result of logic rule 1 in logic rule.
[28] LogicRule 2 Use result of logic rule 2 in logic rule.
[29] LogicRule 3 Use result of logic rule 3 in logic rule.
[30] LC Timeout0 Use result of timer 0 in logic rule.
[31] LC Timeout1 Use result of timer 1 in logic rule.
[32] LC Timeout2 Use result of timer 2 in logic rule.
[33] DigitalInput_18 Use value of DI 18 in logic rule.
[34] DigitalInput_19 Use value of DI 19 in logic rule.
[35] DigitalInput_27 Use value of DI 27 in logic rule.
[36] DigitalInput_29 Use value of DI 29 in logic rule.
[38] DigitalInput_33
[39] StartCommand This event is True, if frequency converter is started by any means (digital input or other).
[40] DriveStopped This event is True, if frequency converter is stopped or coasted by any means (digital input or other).
13-41 Logic Rule Operator 1
Array [4]
Select first logical operator to use on boolean inputs from par. 13-40 and 13-42.
[0] * Disabled Ignores parameters 13-42, 13-43 and 13-44.
[1] And Evaluates expression [13-40] AND [13-42].
[2] Or Evaluates expression [13-40] OR [13-42].
[3] And not Evaluates expression [13-40] AND NOT [13-42].
[4] Or not Evaluates expression [13-40] OR NOT [13-42].
[5] Not and Evaluates expression NOT [13-40] and [13-42].
[6] Not or Evaluates expression NOT [13-40] OR [13-42].
[7] Not and not Evaluates expression NOT [13-40] AND NOT [13-42].
[8] Not or not Evaluates expression NOT [13-40] OR NOT [13-42].
13-42 Logic Rule Boolean 2
Array [4]
Select second boolean input for selected logic rule.
See par. 13-40 for choices and descriptions.
13-43 Logic Rule Operator 2
Array [4]
Select second logical operator to use on boolean inputs calculated in par. 13-40, 13-41, and 13-42 and the boolean
input from par. 13-42.
[0]
* Disabled Ignores parameter 13-44.
[1] And Evaluates expression [13-40/13-42] AND [13-44].
[2] Or Evaluates expression [13-40/13-42] OR [13-44].
[3] And not Evaluates expression [13-40/13-42] AND NOT [13-44].
[4] Or not Evaluates expression [13-40/13-42] OR NOT [13-44].
