16-50 External Reference

Range:

Function:

0.0%

*

[-200.0 - 200.0%]

View sum of all external references in percent.

16-51 Pulse Reference

Range:

Function:

0.0 %

*

[-200.0 - 200.0%]

View actual pulse input converted to a reference in percent.

16-52 Feedback

Range:

Function:

0.000

*

[-4999.000 - 4999.000]

View analog or pulse feedback in Hz.

4.13.7. 16-6* Inputs and Outputs

Parameters for reporting the digital and analog IO ports.

16-60 Digital Input 18, 19, 27, 33

Range:

Function:

0

*

[0 - 1111]

View signal states from active digital inputs.

16-61 Digital Input 29

Range:

Function:

0

*

[0 - 1]

View signal state on digital input 29.

16-62 Analog Input 53 (volt)

Range:

Function:

0.00

*

[0.00 - 10.00 V]

View input voltage on analog input terminal.

16-63 Analog Input 53 (current)

Range:

Function:

0.00

*

[0.00 - 20.00 mA]

View input current on analog input terminal.

16-64 Analog Input 60

Range:

Function:

0.00

*

[0.00 - 20.00 mA]

View actual value at input 60 either as reference or protection value.

16-65 Analog Output 42 [mA]

Range:

Function:

0.00 mA

*

[0.00 - 20.00 mA]

View output current on analog output 42.

16-68 Pulse Input

Range:

Function:

20 Hz

*

[20 - 5000 Hz]

View input frequency on pulse input terminal.

16-71 Relay Output [bin]

Range:

Function:

0

*

[0 - 1]

View relay setting.

16-72 Counter A

Range:

Function:

0

*

[-32768 - 32767]

View present value of Counter A.
