[5] Not and Evaluates expression NOT [13-40/13-42] and [13-44].
[6] Not or Evaluates expression NOT [13-40/13-42] OR [13-44].
[7] Not and not Evaluates expression NOT [13-40/13-42] AND NOT [13-44].
[8] Not or not Evaluates expression NOT [13-40/13-42] OR NOT [13-44].
13-44 Logic Rule Boolean 3
Array [4]
Select third boolean input for selected logic rule.
See par. 13-40 for choices and descriptions.
4.10.6. 13-5* States
Parameters for programming the Logic Controller.
13-51 Logic Controller Event
Array [20]
Select boolean input to define Logic Controller Event.
See par. 13-40 for choices and descriptions.
13-52 LC Controller Action
Array [20]
Select action corresponding to LC event. Actions are executed when corresponding event (par. 13-51) is evaluated as
True.
[0] * Disabled Function is disabled.
[1] No Action No action is taken.
[2] Select Set-up1 Changes active set-up to Set-up 1.
[3] Select Set-up2 Changes active set-up to Set-up 2.
[10] SelectPresetRef0 Selects preset reference 0
[11] SelectPresetRef1 Selects preset reference 1
[12] SelectPresetRef2 Selects preset reference 2
[13] SelectPresetRef3 Selects preset reference 3
[14] SelectPresetRef4 Selects preset reference 4
[15] SelectPresetRef5 Selects preset reference 5
[16] SelectPresetRef6 Selects preset reference 6
[17] SelectPresetRef7 Selects preset reference 7
[18] SelectRamp1 Selects ramp 1
[19] SelectRamp2 Selects ramp 2
[22] Run Issues start command to frequency converter.
[23] RunReverse Issues start reverse command to frequency converter.
[24] Stop Issues stop command to frequency converter.
[25] Qstop Issues quick stop command to frequency converter.
[26] DCstop Issues DC stop command to frequency converter.
[27] Coast Frequency converter coasts immediately. All stop commands including coast command stop the Logic Controller.
[28] Freeze Output Freezes output frequency.
[29] StartTimer0 Starts timer 0.
[30] StartTimer1 Starts timer 1
[31] StartTimer2 Starts timer 2
[32] SetDO42Low Set Digital output 42 low.
[33] SetRelayLow Set Relay low.
[38] SetDO42High Set Digital output 42 high.
