16-12 Motor Voltage

Range:

Function:

0.0

*

[0.0 - 999.9 V]

View motor phase voltage.

16-13 Frequency

Range:

Function:

0.0 Hz

*

[0.0 - 400.0 Hz]

View output frequency in Hz.

16-14 Motor Current

Range:

Function:

0.00 A

*

[0.00 - 655 A]

View motor phase current.

16-15 Frequency [%]

Range:

Function:

0.00

*

[-100.00 - 100.00%]

View a two-byte word reporting actual motor frequency as a percentage of par. X-XX

16-18 Motor Thermal

Range:

Function:

0%

*

[0 - 100%]

View calculated thermal motor load as percentage of estimated thermal motor load.

4.13.5. 16-3* Drive Status

Parameters for reporting the status of the frequency converter.

16-30 DC Link Voltage

Range:

Function:

0 V

*

[0 - 10000 V]

View DC-link voltage.

16-34 Heat Sink Temp.

Range:

Function:

0

*

[0 - 255

rC]

View heat sink temperature of frequency converter.

16-35 Drive Thermal

Range:

Function:

0%

*

[0 - 100%]

View calculated thermal load on frequency converter in relation to estimated thermal load on frequency converter.

16-36 Drive Nom. Current

Range:

Function:

0.00 A

*

[0.01 - 655A]

View continuous nominal drive current.

16-37 Drive Max. Current

Range:

Function:

0.00 A

*

[0.1 - 655A]

View intermittent maximum drive current (150%).

16-38 Logic Controller State

Range:

Function:

0

*

[0 - 255]

View number of active Logic state.

4.13.6. 16-5* Ref. & Feedb.

Parameters for reporting the reference and feedback input.

AF-60 LP™ Micro Drive Programming Guide

59
