Elgar Electronics Corporation
Calibration
2.4.6
CC M
ODE
, L
EVEL
H
IGH
, R
ANGE
II O
FFSET AND
G
AIN
, I
TEMS
19
AND
20
1.
LOAD OFF.
2.
Press the
© key to go to Item 19.
3.
PRES ON.
4.
Set the load current as shown in Table 2-19 for the model being
calibrated.
5.
PRES OFF.
6.
LOAD ON.
7.
Adjust using the
keys until the shunt current and the current
setting match.
MODEL
Current Setting
MODEL
Current Setting
SLM-60-30-150 0.00A SLH-60-120-600 0.00A
SLM-60-60-300 0.00A SLH-60-120-1200 0.00A
SLM-250-10-300 0.00A SLH-60-120-1800 0.00A
SLM-500-10-300 0.00A SLH-60-240-1200 0.00A
SLM-60-15-75 0.00A
SLH-60-240-1800 0.00A
SLH-60-360-1800 0.00A
SLH-500-60-1800 0.00A
Table 2-19. CC Mode, Level High, Range II Offset Adjustment Settings (Item 19)
8.
LOAD OFF.
9.
Press the
© key to go to Item 20.
SLM/SLH Calibration Manual
2-15
