7
Installation
b
• If the [AutoPlay] dialog does not automatically start up:
1) Move the pointer over the lower-left corner of the screen.
→ appears.
2) Right-click and select [Run] in the command list.
→ The [Run] dialog box appears.
3) Type in the full path to the installer, and then click [OK] to start up the installer.
For example: F:\Palette Ver.10\setup.exe (where "F:" is the drive name used for "Palette Software
Key")
• For Windows
®
7 users, click , then [All Programs]. Select [Accessories] and then click [Run] to
display the [Run] dialog box. Type in the full path to the installer in the input window.
2
Click the message appearing in the
top-right corner of the screen.
→ The [AutoPlay] dialog box
continues to be displayed.
3
Click [Open folder to view files].
→ The [File Explorer] window
appears.
4
Open the [Palette Ver.10] folder, and
then double-click the setup.exe file.
→ The [User Account Control] dialog
box appears.
5
Click [Yes].
→ After a short while, the following
dialog box automatically appears.
