41
Practical Application c
Emblem – Using the Template wizard –
Step 2
Editing the text
Step 3
Outputting the design data
1
Click "SUMS" in the text edit box,
and then click [Edit Text].
→ The text "SUMS" is highlighted and
can be edited.
2
Use the keyboard to type "N.U.H.S",
and then press the <Enter> key.
→ The text "since 1831" in the second
row is highlighted and can be
edited.
3
Use the keyboard to type "since
1914", and then press the <Enter>
key.
→ The new text appears in the
preview on the left side of the dialog
box.
4
Click [Next].
→ The [Output] dialog box appears.
1
Click the [Send to] selector to select
where to output the data, and then
click [USB Media] in the appropriate
drive.
2
Click [Send].
→ The data for the template design is
copied to the selected USB media,
and then the message "Finished
outputting data." appears.
3
Click [OK].
Transfer the data to an embroidery
machine to sew your project.
