INPUT
:
5VDC,
3A
POWER
NETW
ORK
SPEAKERS
LINE LEVEL OUT
DIGITAL
SOUND
PROCES
SOR
SOUNDT
RAXX
Durango
, CO 813
01
USA
1/2
3/4
5/6
®
1/8” mini-plug
to RCA
Y-Adapter (not
included)
1/8”
mini-plug to
RCA
Y-Adapter
(not
included)
Optional
Subwoofer
connection
Subwoofer
Left
In
Right
In
Amplifier 3
Left
In
Right
In
Amplifier 2
Left
In
Right
In
Amplifier 1
Left
In
Right
In
When you are using an external amplifier for all system sounds, the speaker
wiring harness is not needed.
Finally, connect the 5VDC power supply included with SurroundTraxx to the
POWER input. The power supply then plugs into a standard 120V to 220V
household outlet.
Your final installation should resemble the master diagram on the following
page.
