Getting Started with iControl
Network Considerations & Port Usage
84
Network Considerations & Port Usage
Network Considerations
In general, large iControl systems (with multiple Application Servers, and a moderate amount
of streaming) have the following client-to-server communication requirements:
• less than 100 ms of latency
• an available bandwidth of 1 Mbit/s (sustained)
• an available bandwidth of 5 Mbit/s (peak)
The sustained bandwidth requirement may be higher, depending on the number of streams
(see
"Allégro-1 Bandwidth Requirements" , on page 84 and "Densité Probe Bandwidth
Requirements" , on page 84).
Allégro-1 Bandwidth Requirements
The table below provides an Allégro-1’s typical bandwidth (bit rate) requirements, based on
using the MVC-3 codec:
Densité Probe Bandwidth Requirements
The tables below provide typical bandwidth (bit rate) requirements (per card) for Densité
cards capable of audio/video streaming (SCP-, ACP-, VCP- and DCP-series).
Note: iControl does not support NAT (Network Address Translation). Reverse NAT or
double-NAT techniques can be used as an alternative.
Image Size Frame rate Hi Quality (Medium
bandwidth, Audio)
Low Quality(Low
bandwidth, Audio)
1024 × 768 15 fps
30 fps
1500 kbps
2200 kbps
800 kbps
1300 kbps
800 × 600 15 fps
30 fps
1000 kbps
1600 kbps
600 kbps
800 kbps
640 × 480
Full 601 Resolution
15 fps
30 fps
500 kbps
625 kbps
225 kbps
285 kbps
320 × 240
1/2 601 Resolution
15 fps
30 fps
200 kbps
250 kbps
60 kbps
90 kbps
176 × 144
1/4 601 Resolution
15 fps
30 fps
100 kbps
125 kbps
30 kbps
40 kbps
88 × 60 15 fps
30 fps
80 kbps
100 kbps
10 kbps
15 kbps
