32
Appendices
AUDIO Menu
([AUDIO] button)
Menu item Value (bold text: default value) Explanation
MEMORY1–MEMORY8
HDMI IN 1
:
HDMI IN 4
AUDIO IN
MIC
LEVEL 0– 100 –127
Adjusts the volume level of the respective input audio streams.
* 100 = 0.0 dB, 127 = +6.0 dB
MASTER OUT LEVEL 0– 100 –127
Adjusts the volume level of output audio.
* 100 = 0.0 dB, 127 = +6.0 dB
AUDIO FOLLOW ON, OFF Turns the Audio Follow function on/off.
HDMI IN 1
:
HDMI IN 4
AUDIO IN
MIC
EQ Hi -15– 0 –15dB Boosts or attenuates the high band.
EQ Hi FREQ 700Hz– 8.00KHz –11.0KHz
Adjusts the center frequency when changing the tone quality in the
high band.
EQ Mid -15– 0 –15dB Boosts or attenuates the middle band.
EQ Mid FREQ 20.0Hz– 2.50KHz –10.0KHz
Adjusts the center frequency when changing the tone quality in the
middle band.
EQ Mid Q 0.5 –16.0
Adjusts the width of the frequency band when boosting or
attenuating the middle band.
EQ Lo -15– 0 –15dB Boosts or attenuates the low band.
EQ Lo FREQ 55– 110 –800Hz
Adjusts the center frequency when changing the tone quality in the
low band.
DELAY 0.0 –500.0ms Adjusts the delay time for audio.
MIC COMP ON, OFF Turns the compressor on/off.
MIC COMP-THRESHOLD -50– -16 –0dB
Specifies the level used as the threshold when compressing audio.
Compression is applied to audio that exceeds the level set here.
MIC COMP-RATIO 1.0:1– INF:1
Specifies the degree of compression applied to the audio. The state
in which no compression is applied is defined as “1.”
MIC COMP-ATTACK 0.2– 50 –100ms
Specifies the time until compression starts when audio exceeding
the threshold is input.
MIC COMP-RELEASE 30– 500 –5000ms
Adjusts the length of time until compression ends after audio falls
below the threshold.
MIC GATE ON , OFF Turns the gate on/off.
MIC GATE-THRESHOLD -50– -36 –0dB
Specifies the level used as the threshold for removing audio. Audio
below the level set here is removed.
MIC GATE-RELEASE 30– 800 –5000ms
Adjusts the length of time until the audio is fully attenuated after
audio falls below the threshold.
MIC HPF ON, OFF Turns the high-pass filter on/off.
MAIN EQ Hi -15– 0 –15dB Boosts or attenuates the high band.
MAIN EQ Hi FREQ 700Hz– 8.00KHz –11.0KHz
Adjusts the center frequency when changing the tone quality in the
high band.
MAIN EQ Mid -15– 0 –15dB Boosts or attenuates the middle band.
MAIN EQ Mid FREQ 20.0Hz– 2.50KHz –10.0KHz
Adjusts the center frequency when changing the tone quality in the
middle band.
MAIN EQ Mid Q 0.5 –16.0
Adjusts the width of the frequency band when boosting or
attenuating the middle band.
MAIN EQ Lo -15– 0 –15dB Boosts or attenuates the low band.
MAIN EQ Lo FREQ 55– 110 –800Hz
Adjusts the center frequency when changing the tone quality in the
low band.
HDMI IN 1
:
HDMI IN 4
AUDIO IN
MIC REV SEND 0– 100 –127 Adjusts the send level of audio to Reverb.
