Appendices
Menu item
Value
(bold text: default value)
Explanation
WIPE SW
ON,
OFF
[WIPE] button
MIX SW
ON,
OFF
[MIX] button
CUT SW
ON,
OFF
[CUT] button
FREEZE SW
ON,
OFF
[FREEZE] button
MEMORY SW
ON,
OFF
[MEMORY] button
AUDIO SW
ON,
OFF
[AUDIO] button
EFFECTS SW
ON,
OFF
EFFECTS A and EFFECTS B [ON] buttons
EFFECTS VOL
ON,
OFF
[EFFECTS A] and [EFFECTS B] knobs
OUTPUT FADE VOL
ON,
OFF
[OUTPUT FADE] knob
A/B FADER
ON,
OFF
A/B fader
NO SIGNAL BACK
BLACK
, BLUE
Specifies the background color of channels that have no video input.
UNFIT SIGNAL BACK
BLACK, BLUE,
THRU
Specifies the background color of channels on which video of an
incompatible format is input.
If this is set to “THRU,” video in an unsupported format is output
unchanged, allowing confirmation of the status of the input signal.
Note, however, that the video might contain additional noise artifacts.
EFFECTS TYPE CHANGE
ON
, OFF
If this is “ON,” effect assignments are changed by holding down the
EFFECTS A [ON] button and turning the [EFFECTS A] knob. Operation
for EFFECTS B is the same.
WIPE TYPE CHANGE
ON
, OFF
If this is “ON,” the wipe transition pattern changes with each press of the
[WIPE] button.
MIX TYPE CHANGE
ON
, OFF
If this is “ON,” the mix transition pattern changes with each press of the
[MIX] button.
OUTPUT FADE LEFT
Specifies the functions when turning the [OUTPUT FADE] knob counter-clockwise.
BLACK
The output video is faded-in/out to a black screen.
AUDIO
Adjusts the output volume.
BLK & AUD
Fades-in/out the output video and audio simultaneously. The video
fades to a black screen.
OUTPUT FADE RIGHT
Specifies the functions when turning the [OUTPUT FADE] knob clockwise.
WHITE
The output video is faded-in/out to a white screen.
AUDIO
Adjusts the output volume.
WHT & AUD
Fades-in/out the output video and audio simultaneously. The video
fades to a white screen.
AUTO OFF
ON
, OFF
Turns the Auto Off function on/off.
When set to “ON,” the power to the V-1HD is automatically turned off if
240 minutes elapse with no operation performed on the unit.
COLOR BAR OUTPUT
ON,
OFF
Setting this to “ON” outputs a color bar.
TEST TONE OUTPUT
ON,
OFF
Setting this to “ON” outputs a test tone.
A/B FADER CALIBRATE
—
Calibrates (adjusts) the A/B fader. When you move the A/B fader to the
bus A position, instructions appear in the screen.
In some cases, such as after extended use or after the unit is
transported, it might occur that the video is no longer output at 100%
when the A/B fader is moved all the way to the bus A or bus B position.
If this occurs, execute A/B fader calibration.
FRAME RATE
59.94, 50
Specifies the frame rate.
FACTORY RESET
—
Returns the unit to its factory defaults. When you move the A/B fader to
the bus A position, instructions appear in the screen.
VERSION
—
Displays the version of the system program.
