40
Appendices
Main Specifications
Roland V-1HD: HD Video Switcher
9 Video
Video Processing 4:2:2 (Y/Pb/Pr), 8-bit
Input Connectors HDMI INPUT 1–4
Type A (19 pins) x 4
* HDCP Supported
Output Connectors
HDMI OUTPUT
Type A (19 pins)
* HDCP Supported
HDMI PREVIEW
Type A (19 pins)
* HDCP Supported
Input Formats HDMI
720/59.94p, 720/50p (FORMAT switch = 720p)
1080/59.94i, 1080/50i
1080/59.94p, 1080/50p (FORMAT switch = 1080i or 1080p)
* The input interlaced video signal is converted to progressive video signal by internal
processing.
* The video signal frame rate is selected by SETUP parameters (59.94 or 50).
Output Formats HDMI
720/59.94p, 720/50p (FORMAT switch = 720p)
1080/59.94i, 1080/50i (FORMAT switch = 1080i)
1080/59.94p, 1080/50p (FORMAT switch = 1080p)
* The video signal frame rate is selected in SETUP parameters (59.94 or 50).
Video Effects
Transition CUT, MIX (DISSOLVE/FAM/NAM/MOSAIC), WIPE (30 types), TRANSFORMER (11 types)
EFFECTS
NEGATIVE, EMBOSS, COLORIZE, COLORPASS, POSTERIZE, SILHOUETTE, MONOCOLOR,
FINDEDGE, FLIP, WH-LUMIKEY@, BK-LUMIKEY@, GR-CHROMAKEY@, BL-CHROMAKEY@,
PinP (1/4)@, PinP (1/3)@, PinP (1/2)@, SPLIT (H-STRETCH)@. SPLIT (H-CENTER)@,
SPLIT (V-STRETCH)@, SPLIT (V-CENTER)@
* @ marked Effects are effected common to A-BUS and B-BUS.
9 Audio
Audio Processing Sampling rate 24 bits/48 kHz
Input Connectors
Digital HDMI INPUT 1–4 (19 pins) x 4
Analog
AUDIO IN (RCA pin type)
MIC (Stereo mini type, plug-in power supported)
Output Connectors
Digital
HDMI OUTPUT (HDMI Type A 19 pins)
HDMI PREVIEW (HDMI Type A 19 pins)
Analog
AUDIO OUT (RCA pin type)
PHONES (Stereo mini type)
Input Level
AUDIO IN -10 dBu (Maximum: +8 dBu)
MIC -41– -13 dBu (Maximum: -1 dBu)
Input Impedance
AUDIO IN 15 k ohms
MIC 10 k ohms
Output Level
AUDIO OUT -10 dBu (Maximum: +8 dBu)
PHONES 72 mW + 72 mW (32 ohms)
Output Impedance
AUDIO OUT 1k ohms
PHONES 10 ohms
Audio Effects EQ, Delay, Compressor, HPF, Gate, Reverb, Mastering effect
9 Other Connectors
USB B Type (for remote control from PC)
MIDI IN, OUT/THRU
9 Other Functions
MEMORY (8 types), FREEZE (input video captured), BPM SYNC (auto transition synchronized to tempo),
OUTPUT FADE (WHITE/BLACK/AUDIO)
