Page 16 DC1048 Integrated Audio Management Operator’s Manual
Menus
Overview
The DC1048 has been designed to be quick to set up and simple to operate. To
facilitate this, the options available for configuration on the front panel have been
deliberately minimized and are explained in detail below.
COMMS Menu
Mode: Mode: Mode: Mode: Master Master Master Master Connect to USB on front
Slave Slave Slave Slave Connect to RS485 on rear
Off Off Off Off Disable remote comms
ID Number: ID Number: ID Number: ID Number: 1 1 1 1 –––– 32 32 32 32 Set address for remote access
RS Baud: 4800 RS Baud: 4800 RS Baud: 4800 RS Baud: 4800 –––– 15200k 15200k 15200k 15200k Baud rate for RS485 ONLY
GPI Menu
GPI: GPI: GPI: GPI: Panel Mode Panel Mode Panel Mode Panel Mode Connect to a WP-1048 touch panel
Complx Mde Complx Mde Complx Mde Complx Mde Binary coded input for up to 16 presets
Simple Mde Simple Mde Simple Mde Simple Mde One wire per preset (4)
Disabled Disabled Disabled Disabled Ignore GPI inputs
Mem. Offset = 0 Mem. Offset = 0 Mem. Offset = 0 Mem. Offset = 0 –––– 16 16 16 16 Preset recalled is input + this number
TX TX TX TX Presets = No/Yes Presets = No/Yes Presets = No/Yes Presets = No/Yes Transmit a recall message on RS485
System Menu
Sys. Lock: Sys. Lock: Sys. Lock: Sys. Lock: Full Full Full Full All front panel functions disabled
Menu Menu Menu Menu Only preset recall allowed
Off Off Off Off All access allowed
On Delay: 0 On Delay: 0 On Delay: 0 On Delay: 0 –––– 60 secs 60 secs 60 secs 60 secs Time before audio output on power up
LCD Contrast: 0 LCD Contrast: 0 LCD Contrast: 0 LCD Contrast: 0 –––– 10 10 10 10 Adjust LCD contrast
LED Timeout: 5 LED Timeout: 5 LED Timeout: 5 LED Timeout: 5 –––– 90 secs 90 secs 90 secs 90 secs Time for backlight and buttons to stay on
