Fluke Biomedical ESA612 - Manual (Page 23)

Electrical Safety Analyzer
Instrument Familiarization
9
Table 3. Side and Top-Panel Connections
Item Name Description
1 Equipment Outlet
Equipment outlet, specific to the version of the Analyzer, which provides a DUT
connection.
2
USB Device Port
(Mini B-style connector)
1
Digital connection for controlling the Analyzer from a PC or instrument
controller.
3 Fuse Access Door Covers the equipment outlet fuses.
4 Tilt Stand Support for holding the Analyzer in a tilted position.
5 AC Power Switch Turns ac power on and off.
6 Power Input Connector
A grounded male three-prong (IEC 60320 C19) connector that accepts the
line-power cord.
7 ECG/Applied Parts Jacks
Connection posts for Device Under Test (DUT) applied parts, such as ECG
leads. Used to test for leakage current through leads and to supply ECG
signals and performance waveforms to a DUT.
8 Banana Jack to ECG Adapter Adapter for connecting ECG snap leads to the Analyzer.
9 Carry Handle
Handle to transport Analyzer. Note: There is no handle on old versions of the
analyzer.
1 Older versions of the Analyzer have a B-style USB port connector.
