ESA612
Users Manual
72
Detailed Specifications
Test Standard Selections ........................................ ANSI/AAMI ES-1, IEC62353, IEC60601-1, and AN/NZS 3551
Voltage
Ranges (Mains voltage) ...................................... 90.0 to 132.0 V ac rms
180.0 to 264.0 V ac rms
Range (Point-to-point voltage) ............................ 0.0 to 300.0 V ac rms
Accuracy .............................................................
± (2 % of reading + 0.2 V)
Earth Resistance
Modes ................................................................. Two terminal
Test Current ........................................................ >200 mA ac
Range ................................................................. 0.000 to 2.000
Ω
Accuracy ............................................................. ± (2 % of reading + 0.015 Ω )
Equipment Current
Range ................................................................. 0.0 to 20.0 A ac rms
Accuracy .............................................................
± (5 % of reading + (2 counts or 0.2 A, whichever is greater))
Duty cycle ........................................................... 15 A to 20 A, 5 min. on/5 min. off
10 A to 15 A, 7 min. on/3 min. off
0 A to 10 A, continuous
Leakage Current
Modes* ................................................................ AC+DC (True-rms)
AC only
DC only
* Modes: AC+DC, AC only, and DC only available for all leakages with exception of MAP
that are available in True-rms (shown as AC+DC)
Patient Load Selection ........................................ AAMI ES1-1993 Fig. 1
IEC 60601: Fig. 15
