Date: 03/31/09, Rev: 09-03 Page 11 of 30 TM.G7SW.064
4.1 Parameters (continued)
Control Mode *1
Paramete
r
Numb
er
Modbu
s
Addre
ss
Parameter Name
Digital Operator
Display
Description
Ran
ge
Default
Cha
nge Duri
ng
Run
V/f
V/f w/ P
G
Open Lo
op
Vector 1, 2 F
lux Vector
P3-03 616H
Position
Regulator Filter
Time
Pos Filter Time
Sets the filter time of the
position regulator output. This
is a first order lag filter.
Note: ELS modes only.
0.00 ~
1.50
sec
0.00 Yes – – – A
P3-04 617H
Position PI Limit
Pos PI Limit
Sets the limit (+/-) of the
position regulator output. Set
as a percentage of the
maximum output frequency
E1-04.
Note: ELS modes only.
0.00 ~
10.00
%
8.00 Yes – – – A
P3-05 618H
Position
Regulator Trim
Mode
Pos Trim Mode
Selects how the position
regulator output is used to trim
the follower drive speed
reference (master encoder
frequency).
0: Constant
The position regulator
output is independent of the
master encoder speed
reference.
1: Speed Prop
The position regulator
output is proportional to the
master encoder speed
reference.
Note: ELS modes only.
0 ~ 1 0 Yes – – – A
P3-06 619H
Speed
Proportional
Position Trim
Lower Limit
SpdProp
LowerLim
Sets the lower limit of the
position regulator trim when
P3-05 = 1. 0.00 ~
100.00
%
10.00 Yes – – – A
P3-07 61AH
Ratio Change
Speed Agree
Width
RatioChg
SpdAgrF
Sets the frequency width used
to determine “Speed Agree”
when the drive is accelerating
or decelerating due to one of
the following:
ƒ Gear ratio change
ƒ Change in state of the
Follower Disable multi-
function input
ƒ Change in state of the run
command
0.0 ~
20.0
Hz
0.5 Yes – – – A
*1: Access Level (A1-01): Q = “Quick Start”, A = “Advanced”, F = “Factory”, – = Not Available.
