Item Description
Account
Information Anonymous/Private Site Select the type of account used for logging into the FTP server.
If Anonymous is selected, log in with Anonymous as the account
name and guest as the password.
If Private Site is selected, be sure to specify settings for User Name,
Password and Confirm.
Choices: Anonymous, Private Site
Default: Anonymous
User Name Specify the user name to log in to FTP server when Private Site is
selected.
Range: Up to 20 characters
Password Specify the password to log in to FTP server when Private Site is
selected.
Range: Up to 20 characters
Confirm Type in the password again for confirmation.
Range: Up to 20 characters
Apply button Applies the configuration settings for this window.
Clear button Resets all configuration settings to previous values.
For SMB server
Note:
The Network - SMB screen, set to Enable from Send when sending to SMB server. For details, refer to
“SMB” on page 182.
Item Description
File Destination Destination Name Specify the name of the destination.
Range: Up to 20 characters
Destination Address Specify the destination IP address of SMB server or NetBIOS.
Range: Up to 64 characters
Directory Specify the destination directory on the SMB server.
Range: Up to 128 characters
