Epson AcuLaser CX37DNF - Manual (Page 167)

Item Description
Maximum Search Results Specify the maximum number of destinations displayed after a search.
Range: 5 to 100
Default: 100
Configuration Menu Equivalent:
UTILITY
- ADMIN. MANAGEMENT - LDAP SETTING - MAX. SEARCH RESULTS
Authentication Method Select the authentication method used for logging on to the LDAP server.
If Anonymous is selected, a user name and password are not necessary.
If Simple is selected, a user name and password are necessary.
If Digest-MD5 is selected, use with a general LDAP server. This cannot be used with Active
Directory.
If GSS-SPNEGO is selected, use with Active Directory in Windows.
If NTLMv2 is selected, use NTLM authentication in Windows.
Choices: Anonymous, Simple, Digest-MD5, GSS-SPNEGO, NTLMv2
Default: Anonymous
Configuration Menu Equivalent:
UTILITY
- ADMIN. MANAGEMENT - LDAP SETTING - AUTHENTICATION
Note:
If “ GSS-SPNEGO ” is used, the address of the LDAP server to be used must be specified in the
System - Date/Time - Time Adjustment Settings - NTP Server Address page, and the time on
this machine and the LDAP server must be the same.
LDAP Account Specify the account used to connect to the LDAP server.
Range: Up to 64 characters
Default: anonymous
Configuration Menu Equivalent:
UTILITY
- ADMIN. MANAGEMENT - LDAP SETTING - LDAP ACCOUNT
Password Specify the password used to connect to the LDAP server.
Range: Up to 32 characters
Configuration Menu Equivalent:
UTILITY
- ADMIN. MANAGEMENT - LDAP SETTING - LDAP PASSWORD
Domain Name Specify the necessary domain name used to connect to the LDAP server.
Range: Up to 64 characters
Configuration Menu Equivalent:
UTILITY
- ADMIN. MANAGEMENT - LDAP SETTING - DOMAIN NAME
Apply button Applies the configuration settings in this window.
Epson AcuLaser CX37 Series Reference Guide
Using Web-Based EpsonNet Config 167
