RISCO Group ProSYS 128 - Manual (Page 29)

Access Control User's Manual 29
Adding Enter/Exit Users 6 6 8 8 CODE CODE # # 4 4 2 2
You can add up to 999 users that have only enter/exit access
rights to the system in the following ways:
x By Entering Card Codes for a Group, below
x By Entering Card Codes One-by-One, page 30
x By Passing a Card in a Reader, page 31
NOTE:
Enter/exit users can only open doors; not arm/disarm the system.
If you have different categories of users, it is recommended to
assign a different block of numbers to each access group. This
makes it easier to allocate each category to the required time
schedule. For example, you can assign user numbers 100-199 to
Access Group 1, 200-299 to Access Group 2, and so on.
By Entering Card Codes for a Group
6 6 8 8 CODE CODE # # 4 4 2 2 1 1 1 1
You can add a group of enter/exit users by assigning a batch of
cards in ascending order. For example, you can add a group of
100 cards with sequential user numbers by only entering the first
card code, and the system enters the remaining information
automatically.
NOTE:
When entering card codes for a group, if the system detects a problem, the
process will stop automatically.
¾
To enter card codes for a group of enter/exit users:
1)
ACCESS CONTROL:
1) SETTINGS
ACCESS CONTROL:
1) SETTINGS
From the Access Control menu,
select
[4] Record Users.
2)
RECORD USERS
1) ARM CARDS
Select [2] Entrance Card.
3)
EN. CARDS 100-999
1) BY CARD CODE
Select [1] By Card Code.
