User’s Manual of VC-820M / VC-2400MR Series
4.10 LLDP
Link Layer Discovery Protocol (LLDP) is used to discover basic information about neighboring devices on the local
broadcast domain. LLDP is a Layer 2 protocol that uses periodic broadcasts to advertise information about the sending
device. Advertised information is represented in Type Length Value (TLV) format according to the IEEE 802.1ab standard,
and can include details such as device identification, capabilities and configuration settings. LLDP also defines how to store
and maintain information gathered about the neighboring network nodes it discovers.
4.10.1 LLDP Configuration
Use this page to change LLDP parameters.
Figure 4-10-1: LLDP Configuration
The page includes the following fields:
Object Description
LLDP Status Enable/Disable LLDP.
LLDP hello time You can change LLDP hello time value. The time interval between
the transmission LLDP info packets. Value range is from 5 to 32768.
Default value is 30.
LLDP hold time You can change LLDP hold time value. (The hold time * the hello
time) is the TTL time in the LLDP info packets. Value range is from 2
to 10.
Default value is 4.
