The Page includes the following fields:
Object Description
•
VLAN ID VLAN ID of the group.
• Groups
Group address of the group displayed.
• Port Members
Ports under this group.
Buttons
Auto-refresh : Automatic refresh occurs every 3 seconds.
: Refreshes the displayed table starting from the input fields.
: Updates the table, starting with the first entry in the IGMP Group Table.
: Updates the table, starting with the entry after the last entry currently displayed.
4.8.7 IGMPv3 Information
Entries in the IGMP SSM Information Table are shown on this Page. The IGMP SSM Information Table is sorted first by VLAN ID,
then by group, and then by Port No. Diffrent source addresses belong to the same group are treated as single entry.
Each Page shows up to 99 entries from the IGMP SSM (Source Specific Multicast) Information table, default being 20, selected
through the "entries per Page" input field. When first visited, the web Page will show the first 20 entries from the beginning of the
IGMP SSM Information Table.
The "Start from VLAN", and "Group" input fields allow the user to select the starting point in the IGMP SSM Information Table.
The IGMPv3 Information screen in Figure 4-8-10 appears.
Figure 4-8-10: IGMP SSM Information Page Screenshot
The Page includes the following fields:
Object Description
• VLAN ID VLAN ID of the group.
• Group
Group address of the group displayed.
