User’s Manual of WGSW-20160HP/WGSW-24040HP series
200
The Page includes the following fields:
Object Description
• Port
The Port coulmn shows the list of ports for which you can configure dscp ingress
and egress settings.
• Ingress
In Ingress settings you can change ingress translation and classification settings
for individual ports.
There are two configuration parameters available in Ingress:
 Translate
 Classify
• Translate
To Enable the Ingress Translation click the checkbox.
• Classify
Classification for a port have 4 different values.
 Disable: No Ingress DSCP Classification.
 DSCP=0: Classify if incoming (or translated if enabled) DSCP is 0.
 Selected: Classify only selected DSCP for which classification is enabled
as specified in DSCP Translation window for the specific DSCP.
 All: Classify all DSCP.
•
Egress Port Egress Rewriting can be one of -
 Disable: No Egress rewrite.
 Enable: Rewrite enable without remapped.
 Remap DP Unaware: DSCP from analyzer is remapped and frame is
remarked with remapped DSCP value. The remapped DSCP value is
always taken from the 'DSCP Translation->Egress Remap DP0' table.
 Remap DP Aware: DSCP from analyzer is remapped and frame is
remarked with remapped DSCP value. Depending on the DP level of the
frame, the remapped DSCP value is either taken from the 'DSCP
Translation->Egress Remap DP0' table or from the 'DSCP
Translation->Egress Remap DP1' table.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
