35
Setting the audio output details
How to view settings screen (FBS)
❶ The statuses of the bands appear. It can also switch between
dynamic and static.
Dynamic state.
• Indicates that the feedback frequency is
detected, and the FBS is functioning.
• The feedback frequency remains for 15 seconds
and is then automatically cleared.
• Until a new frequency is detected, the feedback
frequency display is left blank and turns into a
standby state.
Static state.
• Click this icon in a dynamic state to lock the
band and enter a static state.
• Click the icon again to cancel a static state of the
band and enter a standby state.
Standby state.
• Waiting for a new feedback frequency to be
detected.
❷ The frequencies of the detected feedbacks appear.
❸ Select the strength to suppress the feedback.
❹ Select the speed of suppressing the feedback.
❺ Click to reset the detected frequencies. Once reset, new
frequencies are detected (but those of the bands in a static state
are not reset).
❻
Set all bands to a static state.
❼
Click to copy the static bands to the bands of 12-band EQ. The
bands for which the 12-band EQ is turned off are copied.
• Switch the settings of “Detection” ( ❸ ) or “Response” ( ❹ ) to reset the
band frequencies in a dynamic state.
❶ ❷
❸ ❹ ❺ ❻ ❼
