20
• When using manual focus, if the camera is left turned on, the focus may shift due to increase in the temperature of the lens and inside the
camera body. Make sure to recheck the focus before beginning shooting.
[Pan/Tilt Speed]
Changes the pan and tilt speed. Drag the slider knob to the right to increase camera’s operation speed and to the left to
decrease it.
Note
• For the pan/tilt speed, either of [Control by zoom position] or [Control at set speed] can be selected. For details, refer to "Pan/Tilt Speed
[Pan/Tilt]
Moves the angle in the direction of each arrow. Click and hold to continue and release to stop.
[Zoom Speed]
Changes the zoom speed. Drag the slider knob to the right to increase zoom speed and to the left to decrease it.
[Zoom]
Click the
or
button to operate the zoom. Click and hold to continue and release to stop.
Clicking on the Screen
Autofocus
When the operation selection button is set to
, and there is a face of a person in the screen, a face frame appears and
preferentially adjusts the focus to that face. When multiple people are in the screen, the main subject is automatically
determined, and the following face frames are displayed.
When Eye Detection is enabled, a guide frame is displayed at the eye of the face that is judged to be the main subject.
When the operation selection button is set to
and there is no face of a person in the screen, the focus will be adjusted
to the center of the screen.
Also, clicking a subject displays a tracking frame. Even if the subject or the person moves in the screen, it is possible to
continue to focus on as the main subject. By clicking the screen during tracking, tracking will be canceled.
Note
• The following are the main examples of failure to detect faces:
– When the face is extremely small, large, dark, or bright relative to the entire screen
– hen the face is facing sideways or diagonally, or when the face is upside down
– When part of the face is hidden
• The system may accidentally track another subject with similar characteristics. In this case, select the subject again.
Frame representing a non-main face
Frame representing the main face (if even one face)
Eye detection frame: Eye of subject detected as the main subject
Tracking frame
