Manual Focus
When the operation selection button is set to , by clicking on the camera video, the focus will be adjusted to the clicked
position with autofocus and then fixed.
[Focus Guide]
By clicking the operation selection button and selecting [Focus Guide] from the list, the Focus Guide is displayed at the
position where the camera video was clicked. The adjustment direction and adjustment amount from the current focus
position to the focus position are visually indicated by a guide frame. The position can be changed by clicking.
The guide frame turns green when it is in focus or approaches the in-focus point.
[Preset]
It is possible to call the presets registered to the camera.
Register presets on [Preset/Trace Settings].
For details, refer to “Preset Function” (P. 34).
(1) Speed designation
[On]: The time or speed of moving to the pan/tilt/zoom position can be designated.
[Off]: The speed is designated to the speed that was saved when presets were registered.
(2) Speed Mode
Designates the time or speed of moving to the pan/tilt/zoom position when [Speed Specification] is [On]. Click
[Time (sec.)] to specify the time, or click [Speed Level] to specify the speed. Able to change the value by moving the
slider knob or clicking or .
(3) Preset number button
Click a preset number registered to the camera to call the corresponding preset. Numbers not registered to the
camera are indicated in gray.
(4) [Home]
Click to return the camera to the home position.
In focus Far direction
Large adjustment
amount
Far direction
Small adjustment
amount
Near direction
Small adjustment
amount
Near direction
Large adjustment
amount
Cannot determine
adjustment
(2)
(3)
(6)
(5) (4)
(1)
