29
[Black Gamma: Level], [Black Gamma: Range], [Black Gamma: Point]
Corrects gamma in shadow areas. By changing each value, the gamma curve on the black side within the range shown in
the figure below is adjusted. Move the slider knob or click or to change the value.
– Level: Height from the standard gamma
– Range: Width from the Point
– Point: Vertex position
[Knee: Activate], [Knee: Automatic], [Knee: Slope], [Knee: Point], [Knee: Saturation]
Compresses the highlighted areas to suppress the occurrence of blown highlights. Move the slider knob or click or
to change the value.
– Activate: Enables knee adjustment.
– Automatic: Enables automatic knee adjustment.
– Slope: The slope of the knee.
– Point: Indicates the knee point.
– Saturation: Adjusts the color intensity in the highlighted areas.
[Focus]
[Face Detection AE]
When [Face Detection AE] is turned on, the face of the main subject is detected and brightness is automatically adjusted.
[Eye Detection AF]
When [Eye Detection AF] is turned on, the eyes of the main subject are detected, the focus is automatically adjusted, and
the subject is tracked even if it moves.
[Change Main Focus Target]
The main subject can be changed by clicking or at the right side at the top of the screen.
Point Point
Range
Level Level
Ou
tp
ut
Input
Slope Point
Output
Input
Output
Input
