32
[12G-SDI], [HDMI/3G-SDI]
Selects the area to output to the 12G-SDI OUT terminal, the HDMI OUT terminal, or the 3G-SDI OUT terminal.
When [Full Screen] is selected, the video is output at full size without being cropped.
[Target Crop Frame]
Selects the crop frame to be manipulated.
[View]
When set to [On], the crop frame is displayed on the screen. Even when set to [Off], the cropped video is output to the
video output terminal.
[Crop Scale]
Changes the display magnification of the crop frame.
• Crop frame
When the screen is clicked, the crop frame moves centered around the clicked position. The crop frame can also be
moved by dragging the frame. To resize the area of the crop frame, drag a corner of the crop frame or the four sides of
the crop frame to the desired width.
Note
• For details on crop settings, refer to the Settings Guide of the camera.
• The number of areas to crop and output terminals may differ depending on the camera.
