6
This software can be used to operate Canon remote cameras (hereafter referred to as “cameras”) while watching the video.
This software is capable of the following:
• Operation of registered cameras (P. 17)
Pan/Tilt/Zoom, focus operation, and video quality adjustment are available for registered cameras.
• Simultaneous operation of multiple cameras (P. 17)
Simultaneous Pan/Tilt/Zoom and focus operation are available for multiple cameras. It is possible to reproduce the preset
position registered to the camera.
• Trace function (P. 35)
Registered settings such as camera movement and video quality can be applied at a later time.
• Camera operation via keyboard or joystick (P. 38)
Cameras can be operated via keyboard or joystick. Operations can be configured according to use.
For camera operations and features, refer to the Settings Guide of each camera. Also, make sure to configure initial camera
settings before using this software.
Some features and settings are not supported depending on the camera you are using and the mounted lens.
Examples of System Configuration
The following system configuration is available by combining this software with a switcher and a joystick.
What Is Possible With the Remote Camera Control
Application
LAN
SDI
Remote Camera Control Application
Computer
PoE+ Hub
RTMP Server
Switcher
