M-2 TILT
TOP STAGE & VOLT
M-2 TILT
TOP STAGE
M-2 FLAT
TOP STAGE & VOLT
M-2 FLAT
TOP STAGE
M-1 FLAT TOP STAGE WITH VOLT
CONTROL BOX
M-1 FLAT
TOP STAGE
M-1 TILT TOP STAGE WITH VOLT
CONTROL BOX
M-1 TILT
TOP STAGE
1.75” MONITOR
MOUNT
GIMBAL & VOLT
1.58” MONITOR
MOUNT
GIMBAL
1.58”
2-SECTION
POST
1.75”
3-SECTION
POST
1.75”
2-SECTION
INDEX POST
1.58”
2-SECTION
SHORT POST
M-2 GOLD MOUNT
2-BATTERY* BASE
M-2 V-LOCK
2-BATTERY* BASE
M-1 GOLD MOUNT
2-BATTERY* BASE
M-1 V-LOCK
2-BATTERY* BASE
* 3-battery options are available
5
TIP: Find a list of accessories, including the long gimbal handle and 3rd battery mounts, on page 52. Or visit Tiffen.com/steadicam for
the very latest in modular components and accessories for M-1 and M-2 systems.
Steadicam modular components map
