51
Project Operations
EDIUS - Reference Manual
• If a PDZ-1 extended clip list (consists of a single disk) is written back to the disk, select an SMI file in “General” →
“ExtClipList” folder.
• For PDW-U1 (SAM format), select an SMI file in “EDTR” → “EDITLIST name” folder.
• For a PDW-U1 (SAM format) extended clip list, select an SMI file in “General” → “ExtClipList” folder.
3
•
Check [New Sequence] to create a sequence and import an SMI file. If this item is unchecked, the SMI is
imported to the currently selected sequence. The start timecode is the timecode described in the XML file within
the same folder where SMI file is saved.
• If [FileCopy] is checked, the source files are copied to a folder specified by clicking [Browse], and the copied
source files are referenced.
If this item is unchecked, the original source will be referenced.
• The audio clips are placed to A track.
• The settings to import an XDCAM file can be changed through [Importer/Exporter] in [System Settings] →
[XDCAM].
XDCAM Importer Settings 0 P76
1
Note
• If a paired XML file does not exist in the same folder as the selected SMI file, the file cannot be imported correctly.
This XML file contains the start timecode of the timeline and TC mode settings (drop/non drop).
Field Editing Projects on Another PC
The “field editing function” can be used to ensure that projects move smoothly when, for example, checking out projects
edited on a desktop PC and editing them in a limited manner on a laptop PC. When a project that has been checked out
by field editing is opened, a message is displayed to prevent duplicate editing of the project.
Checking Out Projects (Check-out)
Collect the project and source clips referenced by the project in a specified folder on a removable USB storage media.
Instead of the original source files, proxy files for limited editing also can be checked out.
1 Click [File] on the menu bar, and click [Field Editing] → [Check out].
The [Check Out] dialog box appears.
[Check Out] Dialog Box
0 P51
2 Click [Browse], and specify the checkout destination.
3 Set each item and click [OK].
4 Click [Yes].
When checkout is completed, the project is closed, and the [Start Project] dialog box appears. [Check out] is displayed
in [Status] of checked out projects.
3
•
You can check the detailed information of clips transferred by project checkout by the following operation.
Right-click a clip on the timeline or in the bin, and click [Properties]. You can confirm the directory of the
checkout source file and the clip type (proxy/high-resolution) at checkout by clicking the [Check out info] tab.
[Check Out] Dialog Box
0
[Checked Out] Click [Browse], and specify the collection point (e.g. removable USB storage
media) of the project or source clips. Check [Create folder with project name]
to create a folder with the project name in the destination folder.
You can enter a comment in the [Comments] field.
You can check the amount of free space at the checkout destination and the
size of the project data for checking out and field editing at [Drive Space] and
[Required Space]. The numerical value of [Required Space] differs according
to the [Check Out Source Files] and [Check Out Target] setting.
