Subaru 2007 Tribeca - Manual (Page 142)

Instruments and controls
3-19
3
– CONTINUED –
ingly, if the ABS is inoperative, the Vehicle
Dynamics Control system becomes un-
able to provide ABS control. As a result,
the Vehicle Dynamics Control system also
becomes inoperative, causing the warning
light to come on. Though both the Vehicle
Dynamics Control and ABS systems are
inoperative in this case, the ordinary func-
tions of the brake system are still avail-
able. You will be safe while driving with
this condition, but have your vehicle
checked at a SUBARU dealer as soon as
possible.
NOTE
If the warning light behavior is as
shown in the following, the Vehicle Dy-
namics Control system may be consid-
ered normal.
y
The warning light comes on right af-
ter the engine is started but goes out
immediately, remaining off.
y
The warning light comes on after en-
gine startup and goes off while the ve-
hicle is subsequently being driven.
y
The warning light comes on during
driving, but it goes out immediately
and remains off.
T Traction Control system OFF indica-
tor light
y It comes on when the Traction Control
system OFF switch is pressed.
y It also comes on when the Traction
Control system is deactivated.
NOTE
y The light may stay on for a while after
the engine has been started, especially
in cold weather. This does not indicate
the existence of a problem. The light
should go out as soon as the engine
has warmed up.
y
The indicator light comes on when
the engine has developed a problem
and the CHECK ENGINE warning light/
Malfunction indicator lamp is on.
The Vehicle Dynamics Control system is
probably faulty under the following condi-
tion. Have your vehicle checked at a
SUBARU dealer as soon as possible.
y
The light does not go out even after the
lapse of several minutes (the engine has
warmed up) after the engine has started.
„ Security indicator light
The indicators are located in the center
portion of the dashboard.
This indicator light shows the status of the
alarm system. It also indicates operation
of the immobilizer system.
T Alarm system
It blinks to show the driver the operational
status of the alarm system. For detailed
information, refer to the “Alarm system”
section in chapter 2.
T Immobilizer system
This light blinks approximately 60 seconds
after the ignition switch is turned from
“ON” position to the “ACC” or “LOCK” po-
sition or immediately after the key is pulled
out. (Refer to the “Door locks” section in
200702
