6-24
Interior equipment
1) Vehicle width line (oblique vertical line)
2) Approx. 10 feet (3 m) from the bumper
(green horizontal line)
3) Approx. 6.5 feet (2 m) from the bumper
(green horizontal line)
4) Approx. 3 feet (1 m) from the bumper
(yellow horizontal line)
5) Approx. 1.5 feet (0.5 m) from the bumper
(red horizontal line)
When the selector lever is set to position
“R”, the monitor screen displays the dis-
tance markers together with the rear view
image.
NOTE
Approximately 2.6 feet (0.8 m) is need-
ed to open and close the rear gate.
T Difference between screen and ac-
tual road
The distance markers show the distance
for a level road when the vehicle is not
loaded. It may be different from the actual
distance depending on the loading condi-
tions or road conditions.
V When there is an upward slope at
the back
1) 3 feet (1 m)
The distance on the screen looks farther
than the actual distance.
600571
4
5
3 1
1
1
CHECK SURROUNDINGS BEFORE BACKING UP
2
y When moving backward, always
check the back with your eyes
without relying on the distance
markers.
y The actual position may be differ-
ent from the indication of the dis-
tance markers.
y Differences may occur due to
number of passengers or loaded
cargo.
y When the vehicle is on a slope or
when the vehicle is inclined
against the road, the indication is
different from the actual position.
600572
1
