1-70
Seat, seatbelt and SRS airbags
„ SRS airbag system monitors
A diagnostic system continually monitors
the readiness of the SRS airbag system
(including front seatbelt pretensioners)
while the vehicle is being driven. The SRS
airbag system warning light “AIRBAG” will
show normal system operation by lighting
for approximately 6 seconds when the ig-
nition switch is turned to the “ON” position.
The following components are monitored
by the indicator:
y
Front sub sensor (Right-hand side)
y Front sub sensor (Left-hand side)
y Airbag control module (including impact
and rollover sensors)
y
Frontal airbag module (Driver’s side)
y Frontal airbag module (Front passen-
ger’s side)
y Side airbag sensor (Center pillar right-
hand side)
y
Side airbag sensor (Center pillar left-
hand side)
y
Side airbag module (Driver’s side)
y Side airbag module (Front passenger’s
side)
y
Curtain airbag sensor (Rear wheel
house right-hand side)
y
Curtain airbag sensor (Rear wheel
house left-hand side)
y
Curtain airbag module (Right side)
y Curtain airbag module (Left side)
y Seatbelt pretensioner (Driver’s side)
y Seatbelt pretensioner (Front passen-
ger’s side)
y
Seatbelt buckle switch (Driver’s side)
y Seatbelt buckle switch (Front passen-
ger’s side)
y
Driver’s seat position sensor
y Front passenger’s seatbelt tension sen-
sor
y
Front passenger’s occupant detection
system weight sensor
y
Front passenger’s occupant detection
control module
y
Front passenger’s frontal airbag ON
and OFF indicator
y
All related wiring
100385
If the warning light exhibits any of
the following conditions, there may
be a malfunction in the seatbelt pre-
tensioners and/or SRS airbag sys-
tem. Immediately take your vehicle
to your nearest SUBARU dealer to
have the system checked. Unless
checked and properly repaired, the
seatbelt pretensioners and/or SRS
airbags will operate improperly (e.g.
SRS airbags may inflate in a very mi-
nor collision or not inflate in a se-
vere collision), which may increase
the risk of injury.
y
Flashing or flickering of the warn-
ing light
y No illumination of the warning
light when the ignition switch is
first turned to the “ON” position
y Continuous illumination of the
warning light
y Illumination of the warning light
while driving
