Seat, seatbelt and SRS airbags
1-29
1
– CONTINUED –
„ System monitors
SRS airbag system warning light
A diagnostic system continually monitors
the readiness of the seatbelt pretensioner
while the vehicle is being driven. The seat-
belt pretensioners share the control mod-
ule with the airbag system. Therefore, if
any malfunction occurs in a seatbelt pre-
tensioner, the SRS airbag system warning
light will illuminate. The SRS airbag sys-
tem warning light will show normal system
operation by lighting for approximately 6
seconds when the ignition switch is turned
to the “ON” position.
The following components are monitored
by the indicator:
y
Front sub sensor (Right-hand side)
y Front sub sensor (Left-hand side)
y Airbag control module (including impact
and rollover sensors)
y
Frontal airbag module (Driver’s side)
y Frontal airbag module (Front passen-
ger’s side)
y
Side airbag sensor (Center pillar right-
hand side)
y
Side airbag sensor (Center pillar left-
hand side)
y
Side airbag module (Driver’s side)
y Side airbag module (Front passenger’s
side)
y
Curtain airbag sensor (Rear wheel
house right-hand side)
y
Curtain airbag sensor (Rear wheel
house left-hand side)
y
Curtain airbag module (Right side)
y Curtain airbag module (Left side)
y Seatbelt pretensioner (Driver’s side)
y Seatbelt pretensioner (Front passen-
ger’s side)
y
Seatbelt buckle switch (Driver’s side)
y Seatbelt buckle switch (Front passen-
ger’s side)
y
Driver’s seat position sensor
y Front passenger’s seatbelt tension sen-
sor
y
Front passenger’s occupant detection
system weight sensor
y
Front passenger’s occupant detection
control module
y Do not modify, remove or strike
the front seatbelt retractor assem-
blies or surrounding area. This
could result in accidental activa-
tion of the seatbelt pretensioners
or could make the system inoper-
ative, possibly resulting in seri-
ous injury. Seatbelt pretensioners
have no user-serviceable parts.
For required servicing of front
seatbelt retractors equipped with
seatbelt pretensioners, see your
nearest SUBARU dealer.
y When discarding front seatbelt re-
tractor assemblies or scrapping
the entire vehicle due to collision
damage or for other reasons, con-
sult your SUBARU dealer.
100385
