Page 375
12-8
Specifications
Bulb chart
Fuse panel
Fuse rating
Circuit
1
30A
y
Vehicle dynamics control unit
2
25A
y
Sub fan
3
25A
y
Main fan
4
15A
y
Headlight (right side)
5
15A
y
Headlight (left side)
6
20A
y
Backup
7
15A
y
Horn
8
25A
y
Rear window defogger
9
15A
y
Fuel pump
10
15A
y
Automatic transmission control unit
11
7.5A
y
Engine control unit
12
15A
y
Turn and hazard warning flasher
13
20A
y
Parking switch
14
7.5A
y
Alternator
Description
Wattage
Bulb No.
Headlight
Low beam
12V-55W
H7
High beam
12V-65W
H9
Fog light
12V-55W
H3
Front turn signal/Parking light
12V-28/8W
2357NA
Parking/Front side marker light
12V-5W
168(W5W)
Rear combination light
Rear turn signal light
12V-21W
(W21W)
Brake/tail
12V-21/5W
(W21/5W)
Tail light
12V-3.8W
194
Backup light
12V-16W
921
License plate light
12V-5W
168(W5W)
Cargo area light
12V-13W
–
Dome light
Vehicles with Rear Seat
Entertainment
12V-5W
–
Vehicles without Rear Seat
Entertainment
12V-8W
–
Map light
12V-8W
–
Door step light
12V-3.4W
–
Rear gate light
12V-5W
(W5W)
