Subaru 2007 Tribeca - Manual (Page 224)

Interior equipment
6-21
6
– CONTINUED –
NOTE
y Do not wipe the camera with alcohol,
benzine or paint thinner. Otherwise,
discoloration may occur. To remove
contamination, wipe the camera with a
cloth moistened with a diluted neutral
detergent and then wipe it with a dry
cloth.
y
When waxing the vehicle, be careful
not to apply the wax to the camera. If it
comes in contact with the camera,
moisten a clean cloth with a diluted
neutral detergent to remove the wax.
y
The camera lens has hard coating to
help prevent scratches. However,
when washing the vehicle or cleaning
the camera lens, be careful not to
scratch the camera lens. Do not use a
washing brush directly on the camera
lens. The monitor screen may be ad-
versely affected.
y
Strong light shined on the camera
lens may develop white light stripes
around the light source. This is not a
malfunction.
„ Position of rear view camera
It is attached to the rear gate.
„ How to use the rear view cam-
era
T To display the rear view camera im-
age
When the selector lever is set to “R”, the
rear view camera automatically displays
the rear view image from the vehicle.
When the lever is set to other positions,
the image before setting to “R” is dis-
played.
1. Set the ignition switch to “ON”.
2. Set the selector lever to “R”.
y If your vehicle is washed with a
high-pressure washer, do not al-
low water to contact the camera
directly. Entry of water in the cam-
era lens may result in condensa-
tion, malfunction, fire or electric
shock.
y Since the camera is a precision
device, do not subject it to strong
impacts. Otherwise, malfunction,
fire or electric shock may occur.
y If mud or snow sticks to or is fro-
zen on the camera, you must be
very careful removing it. Other-
wise, damage done to the camera
may cause a fire or electric shock.
Pour lukewarm water over the
camera to remove mud or ice.
y Do not put a flame close to the
camera or wiring. Otherwise, dam-
age or fire may occur.
y When replacing the fuse, be sure
to use a fuse with the specified
rating. Use of a fuse with a differ-
ent rating may result in a malfunc-
tion.
y If the rear view camera is used for
a long time while the engine is not
operated, the battery may become
completely discharged.
