The base parameters and the definition of the factors depend on the type of contract:
Type 1 Contract:
Figure 49:Create a new tariff (Tariff conditions - Type 1 Contract)
Table 10:Create a new tariff (Tariff Conditions: Base Parameters)
Base Parameters
Parameter Description Range of values
Power base (4) Base power of the customer 100 ... 1000 W
Power multiplier (4) Multiplier of the base power 1 ...100
(4) The Contracted power = Base power x Power multiplier
The contracted power is a fixed value, but it can vary according to the Excess and limiting
factors (See 3.3.- CONTROLLING THE MAXIMUM POWER )
Table 11:Create a new tariff (Tariff Conditions: Definition of factors)
Definition of factors
Parameter Description Range of values
Coefficients of contrated power
Excess
Factor that increases the maximum power of the in-
stallation when the micro-grid is in the bonus mode.
1 ...3
Limitation
Factor that decreases the maximum power of the
installation when the micro-grid is in the restriction
mode
0 ... 1
