SF-2050 User Guide – Rev. G
Airborne (option)
Included with the VueStar
system.
The airborne integrated
antenna (PN: 82-001002-
3001) tracks all GPS, WAAS/EGNOS/MSAS/GAGAN
and StarFire™ signals. Our compact GPS antenna
has excellent tracking performance and a stable
phase center for GPS L1 and L2. This antenna is
listed in the NOAA GPS Antenna Calibration tables,
as NAVAN2008T. The robust housing assembly
features a flat mounting surface with four mounting
holes and a downward facing TNC connector. This
antenna is also certified to 70,000 feet (see
Specifications for restrictions).
L-band (option – SF-2050R only)
The L-band antenna (PN: 82-001003-
0001) tracks StarFire™ signals. This
antenna has excellent tracking
performance of geostationary
satellites for latitudes furthest from the
equator. The robust housing assembly
features a flat mounting surface with
two mounting holes and a 3m coaxial
cable with an SMA and a TNC
connector. A 5/8” surveyors mount is
also available. The SF-2050R uses
the SF-2050M GPS antenna to
receive the GPS and WAAS/EGNOS/
MSAS/GAGAN signals.
1-23
