SF-2050 User Guide – Rev. G
Chapter 2 ................................. Interfacing
This chapter details the SF-2050 GPS sensor
connectors, LED display, appropriate sources of
electrical power, and how to interface the
communication ports.
Electrical Power
A front panel 4-pin LEMO female connector provides
electrical power to the SF-2050. Pin assignments are
given in Table 2; see Figure 4 for pin location on the
connector.
Table 2: External Power Cable Pin-Out
Pin Description
1
2
Return
3
4
Power Input 10 to 30 VDC; 8W
Pins 1 and 2 connect to same internal point in the
SF-2050. Likewise, pins 3 and 4 connect to the same
internal point. The supplied power cable is
constructed using 26 AWG wire.
Power cable longer than 5m (15ft)
must make full use of all four power
pins.
2-29
