Teac US-428 - Manual (Page 15)

15
3.2.1 Windows
The US-428 v3 drivers are available on
the CD as executable installers. You’ll
find two executable installer files on the
disk, labeled as
“US428_Win9x_Install_3_05.exe” (for
Windows 98 Second Edition and
Millennium Edition) and
“US428_Win2k_Install_3_05.exe” (for
Windows 2000 and Windows XP).
Note that we have also included the
individual driver files as a ZIP file, for
users wishing to install via Windows
Hardware Manager. However, we
recommend using the installers, as they
will also locate and uninstall any files
pertaining to older versions of the US-
428 drivers.
Also included on the CD are previous
(v2.0) drivers for your convenience.
To install under Win98SE or ME:
Note: The US-428 will run under Win98
SE (Second Edition) or ME (Millennium
Edition). Due to its limited USB
capabilities, First Edition Win98 is not
recommended.
Note: Run the Installer with US-428
turned OFF.
Double click on the executable file
US428_Win9x_Install_3_05.exe.
(The blue US-428 icon). The
installer will run.
Click the "Setup" button. The
Welcome dialog box will appear.
Click the "Next" button. The driver
files will be installed to your hard
drive.
In some cases, Add Hardware Wizard
may ask for the file "US428WDM.SYS".
Should this occur, click Browse and
direct it to the path
Windows/System32/Drivers.
In some cases, Add Hardware Wizard
may ask for your Win98 CD-ROM if it is
unable to find all the needed system
files. We suggest you have it handy.
The Setup Complete dialog will
appear. Click "Yes, I want to restart
my computer", followed by the Finish
button. The computer will reboot.
Connect the US-428 to the
computer, plug it in, and turn it on.
The Windows plug-n-play will notice
a new USB device and start the Add
New Hardware wizard, which will
find the needed files on its own. This
will take about 30-60 seconds.
The drivers are now installed and the
US-428 is ready to operate.
To install under Win2K or Windows
XP:
Note: Run the Installer with US-428
turned OFF.
Double click on the executable file
US428_Win2k_Install_3_05.exe.
(The blue US-428 icon). The
installer will run.
Click the "Setup" button. The
Welcome dialog box will appear.
Click the "Next" button. The driver
files will be installed to your hard
drive.
