A2 - 17
YASNAC PCNC Connecting Manual
Appendix 2: Cable Specifications
2.2 Cable Specifications
2.2.1 Cable Drwg. No. DE8400093 (KQVV-SB Type, 0.2mm
2
x 20 pairs)
Appendix Table 2.1 Construction
Note: Place appropriate wadding in the cable if necessary.
Appendix Table 2.2 Characteristics
Item
Cable Configuration
Number of Pairs
20
Conductor
Material
Tinned, annealed copper, stranded wire
Nominal Section
Area mm
2
0.2
Number of Conductors
(per mm)
16/0.12
Dimensions (mm)
0.55
Insulation
Material
Cross-linked vinyl
Thickness (mm)
0.3
Strand
Strand the cores in the following manner.
Winding
Paper tube lap wound
Sheath
Material and Color
Soft vinyl, black
Thickness (mm)
1.2
Finished Cable Diameter
8.0
Continuous Operating Temperature Range
o
C
-30 to +60
Item
Characteristic Value
Max. Conduction Resistance (20
o
C) W/km
113
Min. Insulation Resistance (20
o
C) MW
.
km
50
Withstand Voltage VAC/min.
1000
Continuous Operating Temperature Range
o
C
-30 to +60
