YASNAC PCNC Connecting Manual
Chapter 2: Power Supply
2.2.2
Power Supply to Converter Unit
Converter unit
CIMR-MR5
Fig. 2.2.2.1 Detailed Connection of Power
R
S
T
R/L1
S/L2
T/L3
A1
A2
1L
r
t
TXR MCCB
.
.
200/220/230 VAC-15% to 10%
50/60 Hz +2Hz
MC
1L
MC
TXR
MCCB
1L
MC
TXR
MCCB
FIGURE 2.2.2.1 Detailed Connection of Power
