6) Use
UP/DOWN button to select Change Brake Fluid from
Select Function menu and press Y button.
Important: To complete the brake fluid change process, make
sure vehicle battery is fully charged and is in good condition. The
brake tool keeps detecting battery voltage during the whole
process. Once the voltage is too low to support the operation, a
“STOP: Voltage at control unit SBC xx.xV” message indicating
battery low comes up as below:
If the voltage stays at a low level, the device is not able to proceed
with the service work. So stop the service by holding N button for
at least 1 second, and an “Operation failed!” message comes up.
........
Select Function
.... .
5/7
► 5) Change Brake Fluid
6) Inspect Brake Air
7) ECU Information
........
Change Fluid
.... .
STOP: Voltage at
control unit SBC
10.2V
7) Follow onscreen instructions to complete the first phase of
operation:
- Connect filling and bleeding unit.
- Set pressure: 2.0→2.5 bar.
- Wait until the pressure has built up.
- Open bleeder screw at rear left brake calliper.
- Hold bleeder hose tight.
8) If you wish to move to the second phase of operation, press Y
button as instructed.
If you do not wish to continue the service, press N button to
exit, and an “Operation failed!” message comes up.
