When you have captured the data you want to save, open the Transfer menu and
choose Capture Text. On the secondary menu, choose Stop.
You have now captured, and saved the file to your PC. This file can now be used
in analyzing the communications traffic on the line, and assist in determining
communication errors.
Returning to the Main Menu
Press [M]
to return to the Main menu.
4.2.4 Database
View
Menu
Press [D]
from the Main menu to open the Database View menu. Use this menu
command to view the current contents of the module database. Press [?]
to view
a list of commands available on this menu.
