Televes Serie H-60 User Manual
Page 136
136
Analyzer
3.3.4.3.2.3.- BER
With this function the H60 enables one to measure the parameters of signal quality for the
different digital modulations whilst viewing the spectrum. CBER measures are taken for the
DVB-T, DVB-S, DVB-C and link margin for DVB-T2 (option) and DVB-S2.
- BER measurement -
Once this function has been activated, the measurement for the last type of digital modulation
selected will appear. The different modulations as well as their parameters can be modified
using the following functions:
DVB-T, DVB-T2 (only option 598903), DVB-C, DVB-S, DVB-S2
One can access this function by pressing and holding down the
key (> 1 sec). Doing this
will activate or deactivate the BER spectrum function.
To come out of this function, simply select another measurement or press the
key (Press
and hold > 1 sec) and select the deactivation of this function.
