TV Mode
3.3.3.- Television Mode
When this menu is selected, the mode changes automatically to TV.
If the meter is in analog mode, the demodulated TV signal of the tuned channel will be displayed
on screen if we are in the terrestrial mode. The analog signals of the satellite band will not be
demodulated.
If the meter is in digital mode, the digital measurement screen will be displayed. We can view
the TV signal of a digital channel by pressing the key , or the MPEG option on the menu.
The sub-menu corresponding to this block is the following:
3.3.3.1.- Viewing Mode
By using the functions of this sub-menu we can select the items we wish to be displayed on
the meter screen:
synchronism impulse, television line, combo (television-spectrum) and
teletext .
3.3.3.1.1.- Synchronism
In this case, what is viewed is the representation of the synchronism impulse on the right side
of the screen.
To stop viewing the synchronism impulse, simply press the option once again.
If you are carrying out a digital measurement (power, C/N, BER, MPEG, Constellation,
ECHOES), it will not be possible to view the
synchronism impulse , since the meter is
informed that the channel tuned in is a digital or satellite one, and therefore does not
require the representation of the synchronism impulse.
